Customized fixed car paint booth equipment

Customized fixed car paint booth equipmentIt is a closed spraying workspace designed specifically for automobile manufacturing and maintenance, adopting an airflow organization form of upper supply and lower exhaust. The equipment sends fresh air that has undergone primary filtration into the static pressure chamber through the top air supply system. After secondary filtration, a uniform air curtain is formed to guide the paint mist generated during the painting process to sink into the exhaust ditch with the airflow. The exhaust system purifies the exhaust gas in multiple stages through dry filters and paint mist treatment devices, and ultimately meets the emission standards. The main body of the equipment usually adopts a steel structure frame, and the walls are equipped with composite insulation boards. The interior integrates lighting, ventilation, temperature control, and safety monitoring systems, which can meet diverse needs such as car shell spraying and local repair.

Performance Characteristics

Efficient purification: The two-stage filtration system (coarse efficiency+precision filtration) can capture dust particles with a diameter greater than 4 microns, with a purification efficiency of over 98%, ensuring clean air in the working environment.

Uniform air supply: Adopting an upward air supply and downward exhaust mode, the airflow forms a vertical air curtain at a speed of 0.3-0.5 meters per second, avoiding paint mist from staying in the operator's breathing zone and improving the uniformity of spraying.

Energy saving and environmental protection: Infrared heating technology accelerates the curing of paint film and reduces drying time; Heat exchangers recover waste heat and reduce energy consumption; Water curtain treatment of paint mist reduces exhaust emissions.

Safe and reliable: Explosion proof lighting fixtures, explosion-proof electrical appliances, and pressure relief devices ensure safe operations, sealed structures prevent paint dust accumulation, and comply with industrial safety standards.

Easy to operate: Modular design supports quick assembly and maintenance, automated control system simplifies the operation process, and reduces the need for manual intervention.

Customized fixed car paint booth equipmentApplication field

Furniture manufacturing: suitable for surface spraying of wooden, metal, and plastic furniture, meeting the uniform spraying requirements of irregular furniture and complex curved surfaces.

Industrial coating: provides a dust-free spraying environment for mechanical equipment and metal structures, ensuring coating quality and durability.

Car maintenance: Solve the problem of insufficient sheet metal spraying stations in 4S stores and repair shops, and support body repair and repainting.

Heavy Machinery: Handling ultra long workpieces such as excavator booms and wind turbine towers, breaking through the size limitations of fixed paint booths.

Aerospace: Meet the cleanliness requirements for special primer spraying on aviation aluminum materials, ensuring stable coating performance.
