Domestic actuator three-way diversion and merging electric control valve DLC6100
NegotiableUpdate on 05/14
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
The domestically produced actuator three-way diversion and merging electric control valve DLC6100 $r $n is mainly used in HVAC systems and also in industrial fields. It is equipped with the new Keyou A8 intelligent valve actuator control system, which has powerful expansion functions and reliable stability. $r $n $r $n Model: DLB430, DLB465, DLB4120, DLB4250
Product Details
Domestic actuator three-way diversion and merging electric control valve DLC6100
Mainly used in HVAC systems, it is also applied in the industrial field, equipped with the new Keyou A8 intelligent valve actuator control system, which has powerful expansion functions and reliable stability.
型号： DLB430 DLB465 DLB4120 DLB4250
Mainly used in HVAC systems, it is also applied in the industrial field, equipped with the new Keyou A8 intelligent valve actuator control system, which has powerful expansion functions and reliable stability.
型号： DLB430 DLB465 DLB4120 DLB4250
Travel: 40mm, 100mm
Working voltage: AC24V (AC110, AC220V, AC380V, AC410 optional)
Running speed: 3mm/s, 1mm/s, 0.33mm/s
Control signal: 4-20mA, 0-10V, RS485, switch signal
Control accuracy: 1% (0.1% optional)
Reset function: optional
Adjustment characteristics: Linear (optional proportional)
Valve position feedback: 4-20mA, 0-10V, RS485 optional
Travel setting: automatic travel verification or digital travel setting
Status display: OLED screen display
Environmental temperature: -20~70 ℃
Protection level: IP65
Manual adjustment and position indication function
Adjustment force 1000N-3000N, 5000N-8500N, adjustable in multiple levels from 10000-20000
Directly installed on the valve without adjustment
Automatic zero point tracking valve zero point, automatic compensation for valve core wear, keeping the valve tightly closed
Valve malfunction alarm, actuator malfunction alarm
This actuator is maintenance free
