FSY fiberglass submersible centrifugal pump

FSYFiberglass submersible centrifugal pumpProduct Overview

There are two types of pumps produced by Kemei, WSY and FSY. 1. WSY pump is a vertical fiberglass submersible pumpVortex pumpThe FSY pump is verticalFiberglass submersible centrifugal pumpThe pump extends into the storage tank, and the depth of the storage tank varies, with a design depth of 800mm to 3000mm to be arbitrarily selected. As long as the liquid is higher than the pump body, the liquid delivery can be started without filling. There is a leakage hole under the flat cover plate, and the liquid will not leak outside the storage tank.

The components of this pump that come into contact with the medium are made of polyvinyl butyral modified phenolic glass fiber, which is molded into phenolic glass steel parts at high temperatures. The connecting pipe and outlet pipe are made of phenolic glass steel pipes using a semi dry rolling process. The assembly of the impeller shaft sleeve is bonded to the pump shaft with phenolic adhesive, and all parts of the underwater assembly are bonded with phenolic adhesive. There is no metal contact with the medium when it enters the liquid, and the corrosion resistance is absolutely reliable. The product has excellent properties such as lightweight, high strength, no deformation, temperature resistance, and corrosion resistance. In terms of corrosion resistance, it can partially replace precious metals such as aluminum stainless steel, iron, and titanium alloys. Pump in transmission and rotation direction: The pump is directly driven by an electric motor through a claw type elastic coupling, and the pump rotates clockwise when viewed from the motor end.
Widely used in industries such as chemical, petrochemical, smelting, dyes, pesticides, pharmaceuticals, rare earths, fertilizers, etc., it is the ideal equipment for transporting various non oxidizing acids (hydrochloric acid, dilute sulfuric acid, formic acid, acetic acid, butyric acid) that do not contain suspended solid particles, are not easy to crystallize, and have a temperature not exceeding 100 ℃ on storage tanks.

FSYFiberglass submersible centrifugal pumpModel meaning

FSYFiberglass submersible centrifugal pumpperformance parameters

FSYFiberglass submersible centrifugal pumpstructural diagram

Kaimei Pump Industry Co., Ltdchemical pumpSelection Notice:

1Fiberglass submersible centrifugal pumpProduct name and model,Fiberglass submersible centrifugal pump管道口径，Fiberglass submersible centrifugal pumpUsing head (m),Fiberglass submersible centrifugal pumpMotor power (KW),Fiberglass submersible centrifugal pumpMotor speed (r/min),Fiberglass submersible centrifugal pumpVoltage [V],Fiberglass submersible centrifugal pumpThe suction range used (m),Fiberglass submersible centrifugal pumpName, specific gravity, viscosity, corrosiveness, and toxicity of the medium used
2、 If our company has already been selected by the design unitFiberglass submersible centrifugal pumpModel, please pressFiberglass submersible centrifugal pumpOrder the model directly from the marketing department of Kaimei Pump Industry Company.
3、 Please provide detailed product usage requirements as much as possible to ensure the correctness of our selection and improve the maximum efficiency of use.
