Fluoroplastic is one of the most excellent corrosion-resistant materials in the world today. Our unit uses this material to produce IGF type fluorine lined pipeline pumps. Cooperate with excellent domestic hydraulic models and adopt IS typecentrifugal pumpThe performance parameters are cleverly combined and designed based on the general vertical pump. This product has strong corrosion resistance and can replace precious metals such as 316L stainless steel and titanium alloy. It also has advantages such as high energy consumption, low noise, and reliable performance.

2、 Product features:

1. The pump is a vertical structure with the same inlet and outlet diameters and located on the same centerline. If a protective cover is added, it can be used outdoors.

2. The impeller is directly mounted on the motor bearing with a reasonable configuration, which can effectively balance the radial and axial loads generated by pump operation, thereby ensuring the balance of pump operation and low vibration noise.

3. The shaft seal adopts a combination of ordinary and particle resistant mechanical seals, which are wear-resistant and corrosion-resistant, and can effectively increase the service life of the mechanical seal.

4. Pumps can be operated in series or parallel according to the requirements of flow rate and head.

3、 Scope of use:

The IGF type fluorine lined pipeline pump is suitable for long-term transportation of acids, alkalis, oxidants, and other corrosive liquids of any concentration at temperatures ranging from -85 ℃ to+200 ℃. Guangfa is used in industries such as petroleum, chemical, metallurgical, power, papermaking, flue gas desulfurization, dust removal, food and pharmaceuticals, and synthetic fibers

4、 Model meaning:

5、 Design features:

(1) The pump is a vertical structure with the same inlet and outlet diameters and located on the same centerline. It can be installed in pipelines like a valve, with a compact and beautiful appearance, small footprint, and low construction investment. If a protective cover is added, it can be used outdoors.

(2) The impeller is directly mounted on the extended shaft of the motor, with a short axial dimension and compact structure. The pump and motor bearings are reasonably configured, which can effectively balance the radial and axial loads generated by the pump operation, ensuring smooth pump operation and low vibration noise.

(3) The shaft seal adopts mechanical seal or a combination of mechanical seals, using imported titanium alloy sealing rings, medium-sized high-temperature resistant mechanical seals, and hard alloy materials for wear-resistant seals, which can effectively increase the service life of mechanical seals.

(4) Easy installation and maintenance, no need to disassemble the piping system, just remove the pump coupling nut to extract all rotor components.

(5) Pumps can be operated in series or parallel according to the requirements of flow rate and head.

(6) Vertical and horizontal installation of pumps can be adopted according to the requirements of pipeline layout.
