【1】 Structure Introduction

Worm gear operation of clamp type nickel aluminum bronze D95800 copper butterfly valveThe picture shows a nickel aluminum bronze C95800 butterfly valve, which mainly uses seawater as the medium. Therefore, a three eccentric soft seal structure is adopted, and the butterfly plate seal material is PTFE. The same materials include RPTFE, EPDM, NBR, etc.

Characteristics of Three Eccentric Butterfly Valve:

1. Short structural dimensions, small volume, light weight, and operational aspects

2. Adopting a full axis mechanism, the butterfly plate has high strength and a large overcurrent area

3. The unique three eccentric design reduces sealing friction loss and greatly extends the service life

【2】 Related standards for American standard butterfly valves

Design and Manufacturing: JB/T8527

Structural length: GB/T12221

Connecting flange: GB/T9113

Inspection and pressure testing: GB/T13927

All valves produced by our company are strictly pressurized according to the pressure testing standards. Only after passing the pressure testing can zero leakage butterfly valves be allowed to leave the factory.

Under the above pressure, the test results show that zero leakage can be achieved!

Accept sampling and full inspection from the customer's quality inspection and third-party quality inspection units commissioned by the end customer, but please inform us in advance

【3】 Specific connection size

L=64 is the national standard for the long series of butterfly valves, and there are also short series butterfly valves of the same type, with a structural length of L=46

【4】 Main component materials

Valve body: C95800

Butterfly board: C95800

Valve stem: Monel k400

Butterfly plate seal: EPDM

Bracket: WCB

Worm gear material: QT450

The default bracket is WCB, and the worm gear material is QT450 material. Our company can also produce WCB, CF8, CF8M and other materials according to customer needs

【5】 About our company

Tianke Valve is a professional manufacturer of butterfly valve series products. The company was founded in 2006 with a registered capital of 11.18 million yuan. Since its establishment, we have been dedicated to researching and opening butterfly valve series products,All butterfly valve series products produced by our company now use our unique molds, which can meet relevant standards in terms of valve body wall thickness, flange thickness, and structural length. The casting molds used by most manufacturers in the non market.

Our production range mainly includes flange butterfly valves, clamp butterfly valves, lug butterfly valves, and welded butterfly valves. The nominal pressure ranges from PN1-100150LB-600LB, with specifications from DN40-1400 and NPS2-60. The standards involved include national standards, the Ministry of Chemical Industry, the Ministry of Machinery, as well as export standards such as American, German, Japanese, Russian, and British standards.

Our company produces various types of special steels, including ordinary cast steel WCB, stainless steel 304, 316, 304L, 316L, duplex steel 22052507, nickel aluminum bronze C95800, titanium, and Hastelloy alloy.

That's allPN16-DN100 national standard clamp type long series nickel aluminum bronze C95800 material worm gear operationFor more information, please visit the website of Tianke Valve Enterprise, a Wenzhou manufacturer specializing in the production of high-quality butterfly valves.

，，
