For detailed information about WEG relay RW17-1D3-U017 12450908 or other relay related products, please feel free to call Yaxi Technology, and we will do our best to solve your problem.

Product Details

Introduction to WEG Relay RW Series

RW overload relay is used to protect the load from overheating caused by overload or phase loss. When overload or phase loss occurs in the circuit, the motor current will increase. This increase in current will trigger the trip mechanism, which will activate auxiliary contacts 95-96 (normally closed contacts) and 97-98 (normally open contacts). The auxiliary contact disconnects the load through the contactor. The disconnection time is related to the overload current and the current set by the relay, which is accurately reflected on the relay trip curve. After tripping, it is necessary to wait for the system to return to normal before resetting. The reset process can be completed automatically or manually.

• Available in both three pole and two pole versions

• Tripping heat level 10

• Can be directly coupled to compact contactor series from 7 to 32A (CW07, CWC07... 025) and contactors from 9 to 140A (CWM9... 105 and CWB 9... 125) without accessories

The attachment can be used for installation on a 35mm DIN rail (EN 50022) or fixed with screws

• Complies with the following standards: IEC 60947-4-1, IEC 60529, IEC 60068, VDE 0106, UL-508

• Main certifications: UL, CE, IRAM, BV, NOM ANCE, RCC, PCT

Technical parameters of WEG relay RW17-1D3-U017 12450908

polar number:	3 extreme
Installation method:	direct installation
Rated insulation voltage:	690 V
Rated insulation voltage (compliant withULStandard):	600 V
Rated impulse withstand voltage:	6 kV
Rated operating frequency:	25...400Hz
Suitable for DC loads:	yes
Maximum operating frequency:	15 ops. /h
Main terminal protection level:	IP10
Protection level of auxiliary terminals:	IP20
current range:	11-17 A
最大熔断器	40 gL/gG (type 2 coordination)
Fuse short circuit protection:	6 gL/gG
height:	72 mm / 2.83 in
width:	45 mm / 1.77 in
depth:	82 mm / 3.23 in
gross weight:	0,165 kg / 0.36 lb

Number of poles	3 poles
Mounting type	Direct
Rated insulation voltage	690 V
Rated insulation voltage (acc. to UL)	600 V
Rated impulse withstand voltage	6 kV
Rated operational frequency	25...400Hz
Suitable for use with DC loads	Yes
Maximum operating frequency	15 ops. /h
Degree of protection - main terminals	IP10
Degree of protection - auxiliary terminals	IP20
Current range	11-17 A
Max. Fuse	40 gL/gG (type 2 coordination)
Short circuit protection with fuses	6 gL/gG
Height	72 mm / 2.83 in
Width	45 mm / 1.77 in
Depth	82 mm / 3.23 in
Gross weight	0,165 kg / 0.36 lb
