XST/C-H11T3A1B1V0N Liquid Level Controller

XST/C-H11T3A1B1V0N Liquid Level Controller

The XST/C-H1IT3A1B1VON controller is divided into combinational logic controller and microprogram controller, each with its own strengths and weaknesses. The design of combinational logic controllers is complicated and structurally complex. Once the design is completed, it cannot be modified or expanded, but it is fast. The microprogram controller is easy to design, has a simple structure, and is convenient for modification or expansion. To modify the function of a machine instruction, simply reprogram the corresponding microprogram; To add a machine instruction, simply add a microprogram to the control memory, but it is done by executing a microprogram. The specific comparison is as follows: A combinational logic controller, also known as a hard wired controller, is composed of logic circuits and relies on hardware to implement the functions of instructions.

Digital liquid level display instrument XST/C-H1IT3A1B1VON; Accuracy ± 0.2%; Input 4-20mA; Output 4-20mA

Power supply 220VAC; External supply of 24VDC; (Powerful function: with AH, AHH, AL alarm output function)

1. Design the instruction system of the machine: specify the types of instructions, the number of instructions, and the format and function of each instruction;

2. Preliminary overall design: such as register settings, bus arrangement, arithmetic unit design, connection relationships between components, etc;

3. Draw an instruction flowchart: indicate at what time and what component each instruction performs what operation;

4. Scheduling operation schedule: that is, decomposing each operation into micro operations according to the instruction flowchart, and listing the micro operations that the machine should perform according to time periods;

5. List expressions for micro operation signals, simplify them, and implement them in circuits.

XST/A-H, XST/A, XST/B, XST/C controllers, XST/C-H1IA1B1V0instrument XST/C-H1IT3A1B1VON

XST/C-H11T3A1B1V0N Liquid Level Controller

Product

1. The basic error is better than ± 0.2% F · S. 16 bit A/D converter. The measurement and control cycle is 0.2 seconds, which can be increased to 0.1 seconds. 8-segment polyline function

2. Anti interference design, suppressing fast pulse group interference generated by relays, contactors, etc. on site, with anti-interference capability reaching level III

3. Input signals: thermistor, thermocouple, DC current, DC voltage, remote pressure gauge, etc. Please specify when placing an order

4. Dimensions: 160 × 80 (horizontal/vertical), 96 × 96, 96 × 48 (horizontal/vertical), 72 × 72, 48 × 48 for instrument use

5. Instrument power supply 220V AC, (9~30) V DC (specify when ordering)

The XST/C-H1IT3A1B1VON instrument is used in conjunction with various analog output sensors and transmitters to measure, transform, display, transmit, and control physical quantities such as temperature, pressure, flow rate, liquid level, composition, force, and displacement.

The error is less than 0.2% F.S, and it has calibration and digital filtering functions, which can help reduce the errors of sensors and transmitters, effectively improve the measurement and control accuracy of the system. It is suitable for voltage, current, thermistor, thermocouple, etc mV、 Signal types such as potentiometers and remote pressure gauges

Zui can provide up to 8 alarm outputs, with 10 alarm modes to choose from and independent alarm sensitivity settings. Equipped with delayed alarm function, effectively preventing false alarms caused by interference and other reasons

The transmission output can output the measured and transformed display values in the form of standard current and voltage for use by other devices

A fully transparent, high-speed, networked communication interface that enables data transmission and control between computers and instruments.

Basic configuration sheet display extension function:

1. Alarm setting value digital display

2. Measurement value light column display

3. Alarm output: Up to 4 points can be added for specifications of 160 × 80 and 96 × 96; Up to 3 points can be added to the 96 × 48 specification,

72 × 72, 48 × 48 specifications can add up to 2 points; 160 × 80 aluminum alloy shell type can add up to 8 points

4. Transmission output

5. External ordinary power supply (supplying power to the transmitter): 24V or 12V or 5V, external precision power supply (supplying power to load, pressure and other sensors) 10V or 12V or 0.5~1.5mA

6. Communication interface: RS 485 or RS 232

7. Printer interface (excluding printer unit)

8. Laboratory desktop instruments: small desktop (230 × 104) (disk mounted), large desktop (318 × 104)

9. 160 × 80 aluminum alloy shell type
