IHG vertical stainless steel pipeline pump (chemical pump)

NegotiableUpdate on 03/28

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The IHG vertical stainless steel pipeline centrifugal pump (chemical pump) is an extended product of the ISG series single-stage pipeline centrifugal pump. It is designed by our scientific and technological personnel in collaboration with domestic stainless steel pipeline pump experts using excellent hydraulic models from China. Based on the general vertical pump, a chemical pump suitable for corrosive media is derived from the ISG type according to different operating temperatures, media, etc.

Product Details

1stainless steelverticalPipeline centrifugal pumpOverview:

stainless steelverticalPipeline centrifugal pumpAs an extension product of the ISG series single-stage single suction pipeline centrifugal pump, it is selected by our technical personnel in collaboration with domestic stainless steel pipeline pump experts using excellent hydraulic models from China. The performance parameters of the IS centrifugal pump are cleverly combined and designed on the basis of a general vertical pump. At the same time, chemical pumps suitable for corrosive media are derived from the ISG type based on different operating temperatures, media, etc. This series of products has the advantages of high efficiency, energy saving, low noise, and reliable performance. Complies with the latest national standard requirements of JB/T5305 8-93 of the Ministry of Machinery. The product is designed and manufactured according to the international IS02858 standard, and this series of products can use stainless steel raw materials of different materials according to different media.

IIstainless steelverticalPipeline centrifugal pumpProduct Advantages:

1. The pump is a vertical structure with the same inlet and outlet diameters and located on the same centerline. It can be installed in pipelines like a valve, with a compact and beautiful appearance, small footprint, and low construction investment. If a protective cover is added, it can be used outdoors.

2. The impeller is directly installed on the extended shaft of the motor, with a short axial dimension and compact structure. The pump and motor bearings are reasonably configured, which can effectively balance the radial and axial loads generated by the pump operation, ensuring smooth operation, low vibration, and low noise of the pump.

3. The shaft seal adopts mechanical seal or a combination of mechanical seals, using imported titanium alloy sealing rings, medium-sized high-temperature resistant mechanical seals, and hard alloy materials for wear-resistant seals, which can effectively extend the service life of mechanical seals.

4. Easy installation and maintenance, no need to disassemble the pipeline system, just remove the pump coupling nut to extract all rotor components.

5. Pumps can be operated in series or parallel according to the requirements of flow rate and head.

6. Vertical and horizontal installation of pumps can be adopted according to the requirements of pipeline layout.

IIIstainless steelverticalPipeline centrifugal pumpPurpose:

1. Used for transporting clean water and other liquids with physical and chemical properties similar to clean water, suitable for industrial and urban water supply and drainage, high-rise building pressurized water supply, garden sprinkler irrigation, fire pressurization, long-distance transportation, HVAC refrigeration cycle, bathroom and other cold and warm water circulation pressurization and equipment matching, with a temperature of T<80 ℃.

2. Widely applicable to: energy, metallurgy, chemical, textile, papermaking, as well as hotels, restaurants and other boiler high-temperature hot water pressurized circulation transportation, and urban use of warm system circulation pumps. The IRG type has a service temperature T<120 ℃, and the PoGRG type has a service temperature T<240 ℃.

3. Stainless steel vertical pipeline centrifugal pump is used for conveying liquids that do not contain solid particles, are corrosive, and have a viscosity similar to water. It is suitable for industries such as petroleum, chemical, metallurgical, power, papermaking, food and pharmaceutical, and synthetic fiber. The operating temperature ranges from 20 ℃ to 120 ℃.

4. For transporting petroleum products such as gasoline, kerosene, diesel, etc., the temperature of the transported medium is -20 ℃~+120 ℃.

4stainless steelverticalPipeline centrifugal pumpWorking conditions:

1. The suction pressure is less than 1.0 MPa, or the maximum working pressure of the pump system is less than 1.6 MPa, that is, the chemical pump suction inlet pressure+pump head is less than 1.6 MPa, and the pump static pressure test pressure is 2.5 MPa. Please specify the system working pressure when ordering. If the working pressure of the pump system is greater than 1.6 MPa BU, it should be separately stated when ordering. In order to use cast steel materials for the overcurrent and connection parts of the centrifugal pump during manufacturing.

2. Environmental temperature<40 ℃, relative humidity<95%.

3. The volume content of solid particles in the conveyed medium shall not exceed 0.1% of the unit volume, and the particle size shall be greater than 0.2 mm.

Note: If the medium used has small particles, please specify the size on the order date so that the manufacturer can use wear-resistant mechanical seals.

5、 IHG vertical stainless steel pipeline centrifugal pump (chemical pump) model meaning:

6、 Structural diagram of IHG vertical stainless steel pipeline centrifugal pump (chemical pump):

7IHG vertical stainless steel pipeline centrifugal pump (chemical pump)Fault causes and troubleshooting methods:

8IHG vertical stainless steel pipeline centrifugal pump (chemical pump)Installation method:

9IHG vertical stainless steel pipeline centrifugal pump (chemical pump)Performance parameters:
