KBU type engineering plastic pump

NegotiableUpdate on 03/24

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

1、 Overview: KBU type engineering plastic centrifugal pump is a horizontal, single-stage, single suction, bracket type centrifugal pump, which is carefully designed by our factory based on the advantages of corrosion-resistant non-metallic centrifugal pump structures at home and abroad

Product Details

1、 Overview

The KBU engineering plastic centrifugal pump is a horizontal, single-stage, single suction, and bracket type centrifugal pump, carefully designed by our factory based on the advantages of corrosion-resistant non-metallic centrifugal pump structures at home and abroad. The overcurrent components are made of the world's novel engineering plastic ultra-high molecular weight polyethylene (UHMWPE). In terms of corrosion resistance, it is not only the same as F4 and F46, but also has excellent wear resistance and impact resistance. The sealing of the pump adopts various forms such as mechanical seal, power seal, and self-adjusting seal according to different working conditions. It can transport both acidic and alkaline clear liquids, as well as slurry containing solid particles and wastewater containing impurities. Especially in the transportation of corrosive liquids containing fine particles and the transportation of hydrofluoric acid, fluorosilicic acid, phosphoric acid, mixed acids, electrolytes, salt solutions, dilute sulfuric acid, concentrated alkali, etc., it exhibits excellent performance. This series of pumps is suitable for temperatures ranging from -50 ℃ to 90 ℃. After replacing the impeller and pump body with other engineering plastics such as PVDF and F46, the applicable temperature can reach 120 ℃.

2、 Model meaning

100KBU-35-K-A

100	—	Imported diameter (mm)
KBU	—	Wear resistant and corrosion-resistant engineering plastic pump
35	—	Head (m)
K	—	Sealing code (ZK for impurity mortar
K	—	Power seal, K is power seal, C is mechanical seal, Z is self-adjusting seal)
A	—	Improved model

3、 Performance parameter table of centrifugal pump (I)

Model number	Import	seal	Pump rated speed n=2900r/min					Pump rated speed n=1450r/min
	×	form	Pump rated speed n=2900r/min					Pump rated speed n=1450r/min
	Export		internet traffic	lift	npsh	Motor power kW		internet traffic	lift	npsh	Motor power kW
	(mm)		Q	H	(NPSH)r	Motor power kW		Q	H	(NPSH)r	Motor power kW
			m3/h	m	m	1	1.2	m3/h	m	m	1	1.2
32KBU-20	32×25	ZK	5	25	3.8	2.2	3	2.5	6	2.6	1.1	1.1
		K	8	23	3.9	2.2	3	4	5.5	2.5	1.1	1.1
		C	10	20	4	2.2	3	5	5	2.5	1.1	1.1
		Z	12	17	4.1	2.2	3	6	4	2.4	1.1	1.1
			14	15	4.2	3	3	7	3	2.4	1.1	1.1
50KBU-30	50×40	ZK	5	33	4	5.5	7.5	2.5	8	2.3	1.5	1.5
		K	10	32	4.1	5.5	7.5	5	8	2.3	1.5	1.5
		C	15	31	4.1	5.5	7.5	7.5	7.5	2.5	1.5	1.5
		Z	20	30	4.3	5.5	7.5	10	7.5	2.5	1.5	1.5
			25	27	4.3	5.5	7.5	12.5	7	2.5	1.5	1.5
			30	23	4.5	7.5	7.5	15	6	2.8	1.5	1.5
65KBU-50	65×50	ZK	20	58	3.8	15	18.5	10	14.5	2.2	3	3
80KBU-50	80×50	K	30	54	4.1	15	18.5	15	13.5	2.5	3	3
		C	40	50	4.1	15	18.5	20	12.5	2.5	3	3
		Z	50	46	4.4	15	18.5	25	11.5	2.7	3	3
			60	42	5	18.5	22	30	10.5	3	3	3
			65	40	5.4	18.5	22	35	10	3.4	3	4
80KBU-30	80×65	ZK	20	37	4	11	15	10	9	2.3	2.2	3
		K	30	36	4.2	11	15	15	9	2.5	2.2	3
		C	40	35	4.5	11	15	20	8.5	2.8	2.2	3
		Z	50	33	4.7	11	15	25	8	3	2.2	3
			60	28	5	15	15	30	7.5	3.2	3	3
100KBU-35	100×80	ZK	30	43	5.1	15	15	15	11	2.8	2.2	2.2
		K	50	40	5.3	18.5	18.5	25	10	3	3	3
		C	60	38	5.5	18.5	18.5	30	9.5	3.2	3	3
		Z	70	36	5.5	18.5	18.5	35	9	3.2	3	3
			90	32	5.8	18.5	18.5	45	8	3.5	3	4
100KBU-40	100×80	ZK	60	50	5	22	22	30	2.5	2.8	5.5	5.5
100KBU-37		K	80	45	5.3	22	22	40	11	3	5.5	5.5
		C	100	40	5.7	30	30	50	10	3.3	5.5	5.5
		Z	110	38	6	30	30	55	9.5	3.3	5.5	5.5
			120	35	6	30	30	60	9	3.6	5.5	5.5

4、 Performance parameter table of centrifugal pump (II)

model	Import x Export	seal	Pump rated speed n=1450r/min				Pump rated speed n=980r/min
	（mm）	form	internet traffic	lift	npsh	Motor Power	internet traffic	lift	npsh	Electric power
			Q	H	(NPSH)r	kW	Q	H	(NPSH)r	kW
			m3/h	m	m	1＜r<1.4	m3/h	m	m	1
150KBU-30	150×125	ZK	130	30	5.5	30	100	13	5.1	15
150KBU-25		K	200	27	6.1	37	135	12	5.4	15
		C	220	26	6.3	37	145	11.5	5.5	15
		Z	280	22	6.7	37	185	9.5	5.7	15
			300	20	6.7	45	200	9	6.1	18.5
			320	18	6.9	45	215	8	6.2	18.5
150KBU-40	150×125	ZK	100	44	3	37	65	19.5	2.6	15
		K	150	42	3.5	45	100	18.5	3	18.5
		C	200	38	4	45	135	17	3.3	18.5
		Z	250	34	4.5	55	165	15	3.5	22
200KBU-32	200×150	ZK	200	36	5.3	55	135	16	5	22
		K	250	35.5	5.3	55	165	15.5	5.1	22
		C	300	34	6	55	200	15	5.3	22
		Z	350	32	6.3	55	235	14	5.4	22
			400	27	6.5	75	265	12	5.6	30
			420	24	6.6	75	280	10.5	5.7	30
200KBU-27	200×150	ZK	300	34	5.6	75	200	15	5.2	30
		K	350	32	5.8	75	235	14	5.3	30
		C	400	29	6	75	265	13	5.4	30
		Z	440	27	6.3	75	295	12	5.6	30
			500	23	6.5	75	345	9	5.8	30
			520	16	6.7	75	356	7	5.9	30
250KBU-45	250×200	ZK	400	49	5.5	160	265	21.5	5.2	55
		K	450	48	5.7	160	300	21.5	5.3	55
		C	550	47	5.8	160	365	21	5.4	55
		Z	600	45	5.9	160	400	20.5	5.5	55
			650	42	6	160	436	20	5.6	55
			750	32	6.3	160	465	19	5.6	55

Note: This table lists most of the parameters such as flow rate and head. If the selected parameters are not within the range of this table, our factory can use cutting impellers, modified impellers, or other methods that comply with the principle to achieve it.
