RNN-300 nitrogen generator

1、 Product Introduction

The RNN series nitrogen generator is a device used by our company's gas source department to provide purge gas and carrier gas for instruments such as gas chromatography, Fourier transform infrared spectroscopy (FT-IR), total organic carbon analyzer (TOC), nuclear magnetic resonance (NMR), and thermal analyzer.

2、 Product Features

The nitrogen generator can replace high-pressure steel cylinders, and the dual cathode stainless steel electrolytic separation cell can produce nitrogen through electrolysis, produce gas during start-up, and is flexible and convenient.

Low maintenance costs, only pure water needs to be added for continuous use during normal use.

The unique anti backflow device ensures that there is no backflow phenomenon in the instrument, and the third level purity achieves better purification.

A large capacity water storage device allows for continuous operation for several days with a single addition of water.

The purification tube of the disposable stretching mold reduces the leakage point, which is more likely to protect the reliability of the instrument.

3、 Technical parameters

Output flow rate: 0-300ml/min

Output pressure: 0-0.4Mpa

Pressure stability:<0.2%

Nitrogen purity:>99.999%

Liquid tank capacity: 2 liters

Water quality requirement: electrical resistivity ≥ 1M Ω/cm

Power supply: 220V ± 10%, 50-60Hz

Operating environment temperature: 0-40 ℃

Operating environment humidity:<85%
