Dongguan Liuqin Testing Instrument Co., Ltd
Simulated environmental dust test chamber
NegotiableUpdate on 02/12
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Execution method for simulating environmental dust test chamber: $r $n complies with IEC60529:1989 +A1:1999 +A2：2013《Degrees of protection provided by enclosures(IP Code)》、《GB4208-2017 The requirements of clauses 13.4 and 13.5, Figure 3, and clauses 9.2.1 and 9.2.2 of GB7000.1 "Luminaires Part: General Requirements and Tests" regarding the protection level of the enclosure (IP code).
Product Details
The destruction of products and materials by natural dust (such as sand, dust, wind dust, etc.) causes incalculable economic losses every year. The damage caused mainly includes corrosion, fading, deformation, decreased strength, expansion, mold, etc., especially electrical products that are prone to fire due to short circuits caused by sand and dust.
Simulated environmental dust test chamberExecution method:
comply with IEC60529:1989 +A1:1999 +A2：2013《Degrees of protection provided by enclosures(IP Code)》、《GB4208-2017 The requirements of clauses 13.4 and 13.5 of the "Protection Class of Enclosures (IP Code)" and Figure 3, as well as clause 6 of clauses 9.2.1 and 9.2.2 of GB7000.1 "Luminaires Part: General Requirements and Tests".
Equipment box size |
750*800*750mm |
Metal mesh standard line |
50um |
Standard spacing between lines |
75um |
Test dust |
Dry stone powder |
真空度 |
0-10Kpa (adjustable) |
Extraction speed |
0-4800L/H (adjustable) |
equipment power supply |
220V |
Test sample power supply |
220V |
Equipment power |
1.5KW |
protection function |
Leakage protection, water shortage protection, short circuit protection |
Simulated environmental dust test chamberThis device is suitable for testing electrical and electronic products, automotive and motorcycle components, and seals to prevent sand and dust from entering the seals and casings in a dusty environment. To test the performance of electronic and electrical products, automotive and motorcycle components, and seals in the use, storage, and transportation of sand and dust environments.
