Stability testing of dental consistency and compressive strain testing device

NegotiableUpdate on 03/11

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The dental consistency and compressive strain testing device is stable and meets the consistency and compressive strain testing requirements of YY/T 0493-2022 "Dental Elastic Impression Materials"

Product Details

Stability testing of dental consistency and compressive strain testing deviceStability testing of dental consistency and compressive strain testing device

1、 Overview:

This device meets the requirementsYY/T 0493-2022Requirements for Consistency and Compressive Strain Testing of Dental Elastic Impression Materials

2、 Technical parameters:

parameter	Specifications
Consistency test load	（14.71±0.01）N
Working time load of "0" type material	（12.75±0.01）N
Compressive strain load	（12.26±0.01）N
Load rod	Provide an initial force of (1.22 ± 0.01N) for compressive strain
counterweightcontrol accuracy	±0.01N
Range of dial gauge	0~5mm
Precision of dial gauge	0.01mm
Operating Temperature	0~30℃
Operating Humidity	≤60%RH

3、 Execution standards‌：

YY/T 0493-2022Dental elastomer impression materials

4、 Device principle

牙科学稠度及压应变试验装置测试稳定

5、 Configuration List:

1 host;

1 copy of instruction manual;

1 certificate of conformity;

1 warranty card;

One copy of the delivery receipt;

1 nameplate;

1 set of wrench;

Dental viscosity and strain testing device
