FPG vertical engineering plastic vertical pipeline pump

Overview

FPG vertical engineering plastic vertical pipeline pump is made by one-time injection molding of reinforced polypropylene (RPP). High mechanical strength, strong corrosion resistance, medium does not come into contact with metal, mechanical seal has a long service life, high efficiency, and can replace stainless steel and other metal pumps.

RPP material: Non hazardous, non-toxic, resistant to general acids, bases, and salts, with a working temperature range of -14 ℃ to 200 ℃, widely used in chemical pipeline transportation.

2、 Pump usage:

1. Before starting, the pump should be filled with liquid by filling or vacuuming, and it is strictly prohibited to idle or reverse.
2. The conveying fluid of the pump should be free of sediment, particles, and long fiber materials to prevent blockage and damage to the impeller and seal.
3. When the specific gravity of the medium conveyed by the pump is greater than 1.2, an additional motor should be installed to avoid affecting the head or burning out the motor.
4. Before parking, the discharge pipeline valve should be closed first. In the case of backflow, the inlet pipeline valve needs to be closed before shutting down the machine.

structural diagram

Model meaning

performance parameters

performance curve
