High pressure vortex fan vacuum explosion-proof vortex pump gas circulationPrecautions for use

No matter which brand it isVortex high-pressure blowerBoth require protection in two aspects: pressure and dust.
For pressure, a pressure relief valve is often used, which is an unloading valve. When the operating pressure of the high-pressure fan exceeds the set pressure of the pressure relief valve, the pressure relief valve will automatically open to release the excess pressure and protect the high-pressure fan.
For dust, filters are often used. It often uses filter cartridges with different filtration accuracies according to different usage scenarios. Different filter cartridges have different maintenance methods and service lives, which need to be clarified when ordering.
In some special occasions, special protection is also necessary: for example, when using in a sealed environment, attention should be paid to ventilation and heat dissipation; When the ambient temperature (intake temperature is relatively high), it is more important to pay attention to ventilation and heat dissipation, or choose a high-pressure fan that allows for a higher intake temperature (such as a ring blower that allows for an intake temperature of up to 130 ° C);
For certain brandsVortex high-pressure blowerYou may also have your own usage suggestions, so it's important to have a detailed understanding before making a purchase.

Vortex high-pressure blowerPrinciple of material absorption:

When there is no material in the small hopper;
2. The mechanical air switch will fall downwards to open the sensing switch;
3. When the induction switch is turned on, the relay of the host opens to start the motor;
4. The motor operates to drive the exhaust device,
5. Start passing through the air filter to the small hopper,
6. Under the action of suction, the mechanical air switch closes the discharge port upwards, forming a vacuum in the small hopper,
7. There is a material pipe leading to the hopper at the feeding port, and the raw materials begin to enter the small hopper,
8. The raw materials are isolated by a filter screen and will not be sucked into the direction of the motor,
9. Stop the motor when the set operating time is reached,
10. The mechanical air switch of the small hopper dropped after there was no vacuum,
11. The raw materials fall into the dryer and the cycle ends.

Installation precautions:

1. Installation location: It must be installed indoors in a place that is not affected by wind and rain

2. Environmental temperature: below 40 ℃
3. Relative humidity: below 80%
4. Air quality: If the air contains corrosive or flammable gases such as acids and alkalis, it should not be contaminatedVortex high-pressure blowerTransport to avoid danger
5. Dust protection: Avoid using in places with large amounts of dust, powder, or fibers. If it is necessary to use in such places, please install a filter and regularly clean the dust attached to the filter and inside the high-pressure blower
6. Ventilation and heat dissipation: Please choose to use it in a well ventilated place and not in a sealed room or box
7. Placement space: For the convenience of column maintenance or repair, please avoid installing in overly narrow locations
8. Avoid vibration: Please install in a vibration free location; If the vibration in the venue is unavoidable, anti vibration measures must be installed to prevent the high-pressure blower from being damaged by external vibrations.

High pressure vortex fan vacuum explosion-proof vortex pump gas circulationScope of application:
Environmental engineering industry machinery, plastic machinery (dehumidification dryer), printing machinery (screen printing machine), photographic plate making, PCB equipment, electrical appliances
Equipment, medical devices, various combustion machines, environmental protection aquaculture, paper cutting machines, combustion oxygen reduction machines, cigarette filter forming machines, electroplating tank liquid mixing, atomization drying machines, water treatment aeration, aquaculture, screen printing machines, photographic plate making machines, injection molding machines, automatic feeding drying machines, liquid filling machines, powder filling machines, welding equipment, film machinery, paper transportation, dry cleaning clothes, cleaning purposes, air dust removal, dry bottles, gas transmission, feeding, collection, environmental protection water treatment, dust collection environmental protection, aquaculture, screen printing, electroplating, dust removal, food, packaging, filling, glass products, airflow transportation and other industries.
