Laboratory homogenizer for lotion cream

NegotiableUpdate on 02/08

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

EF30 application areas include infinite speed regulation, strong torque output, double-layer stator design structure, and combination of multiple stator groups, which can meet the requirements of dispersion, homogenization, emulsification, mixing and other experiments. $r $n Usage Process: Suitable for low to medium viscosity materials and solid-liquid dispersion, emulsification, homogenization, and mixing. $r $n Laboratory homogenizer for lotion cream

Product Details

EF30 Features and Advantages

ØMultiple combinations of stator functions: standard formula inner stator, long hole inner stator, and circular hole stator. Standard outer stator: circular hole.

ØWork head structure: stator quick disassembly design,Suitable for various working conditions

Laboratory homogenizer for lotion cream

EF30Technical Specifications

Brand Model：	【OuHor RiverEF30	EF50	EF70
electricity Source:	220V/50Hz	220V/50Hz	220V/50Hz
Motor power:	500W	500W	500W
Speed range:	2000~15000rpm	2000~15000rpm	2000~15000rpm
Processing capacity（H20）：	150~5000ml	200~7000ml	500~10000ml
Maximum processing viscosity：	6000CP	6000CP	6000CP
Speed regulation method:	Electronic speed control	Electronic speed control	Electronic speed control
Control function:	Digital display, start stop, electronic speed regulation
Standard working head:	30E comprehensive (single stator, multiple combinations) Internal determinants: small circular hole, elliptical hole, square hole, large circular hole External stator: None	50E comprehensive (double-layer stator, multiple combinations) Internal determinants: circular hole, elliptical hole, square hole External stator: square hole, inclined hole	70E comprehensive (double-layer stator, multiple combinations) Internal determinants: circular hole, elliptical hole, square hole Outer stator: circular hole
Outer stator diameter:	30mm	50mm	70mm
Contact logistics material:	SUS316L	SUS316L	SUS304
Sliding ring material:	copper alloy	copper alloy	copper alloy
Process type:	batch processing
appearancesize：	300200720mm
package weight：	12KG carton foam packaging
Standard configuration:	EF70emulsifierhost1TaiwanSpray coating bracket1Set70Ework head1set、German cross clamp1A tool for disassembling and assembling work heads1Sleeve, carbon brush1Yes, yesCertificate of Conformity for Instruction Manual.

Application advantages

1. * * Efficient emulsification * *: The high shear emulsifier can fully mix the oil phase and water phase in a very short time, achieving the desired emulsification effect and improving production efficiency.
2. * * Delicate and homogeneous * *: The cream liquid foundation prepared by strong shearing and dispersion is fine and uniform in texture, easy to apply, and improves the product quality.
3. * * Wide applicability * *: It is not only applicable to the production of cosmetics such as cream and liquid foundation, but also can be used in many fields such as food, medicine and chemical industry, with wide applicability.
4. * * Automated Control * *: Equipped with a control system to achieve automated control of the production process, reduce the difficulty of manual operation, and improve production stability.
5. * * Easy to clean and maintain * *: The equipment has a reasonable structural design, is easy to disassemble and clean, meets hygiene standards such as GMP, and ensures a clean and safe production environment.

Laboratory homogenizer for lotion cream
