Pull plate filter press

Pull plate filter press

pull boardfilter pressInstructions for using the device:

1Press down“Push the plate tightly”Button, at this time, the main motor of the filter press starts, the solenoid valve for pushing the plate forward opens, and the pushing plate presses forward slowly. When the pressure reaches the pressure value specified by the electric contact pressure gauge, the main motor and solenoid valve automatically close,“pressure holding”The light is on, and the filter press is in a pressure holding state. Pull plate filter press定制Start feeding.

2Press down“停止”Button, at this moment“pressure holding”The light goes out, which means the pressure holding state is turned off.

3Press down“Release the push plate”Button, now pull the plate filter pressbrandThe main motor starts, the solenoid valve for pushing the plate backwards opens, and the pushing plate slowly releases backwards. When it reaches the limit switch, it automatically stops. Then start unloading.

4, will“auto manual”Turn the knob to“automatic”, press down“positive pull”Button, pull the board forward with the puller, and when it touches the board, the puller will automatically reverse and pull the board back; Repeat the process until the plate is fully pulled, then the puller returns to its initial position and stops at the limit.

5, will“auto manual”Turn the knob to“manual”At this point, the main motor starts, using“Pull board adjustment”Use a knob to adjust the forward and backward movement of the puller.
