Fluorine lined pipeline pump
NegotiableUpdate on 05/25
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
GBF25-125 fluorine lined pipeline pump is suitable for long-term transportation of acids, alkalis, oxidants, and other corrosive liquids of any concentration at temperatures ranging from -85 ℃ to+200 ℃. Guangfa is used in sectors such as petroleum, chemical, metallurgical, power, papermaking, flue gas desulfurization, dust removal, food and pharmaceuticals, and synthetic fibers.
Product Details
GBF25-125Fluorine lined pipeline pump
GBF25-125Fluorine lined pipeline pump
Product Special 1: GBF type fluorine lined pipeline centrifugal pump is a vertical structure with the same inlet and outlet diameters and located on the same centerline. If a protective cover is added, it can be used outdoors.
2. The GBF type fluorine lined pipeline centrifugal pump impeller is directly installed on the motor bearing with a reasonable configuration, short axial size, and compact structure. The reasonable configuration of pump and motor bearings can effectively balance the radial and axial loads generated by pump operation, thereby ensuring smooth pump operation and low vibration noise.
3. The shaft seal of GBF type fluorine lined pipeline centrifugal pump adopts a combination of ordinary and particle resistant mechanical seals or mechanical seals, which are wear-resistant and corrosion-resistant, and can effectively increase the service life of the mechanical seal.
4. The GBF type fluorine lined pipeline centrifugal pump can be operated in series or parallel according to the requirements of flow rate and head.
Application and Parameters
Scope of application
The GBF lined fluorine pipeline centrifugal pump is suitable for long-term transportation of acids, alkalis, oxidants, and other corrosive liquids of any concentration at temperatures ranging from -85 ℃ to+200 ℃. Widely used in sectors such as petroleum, chemical, metallurgical, power, papermaking, flue gas desulfurization, dust removal, food and pharmaceuticals, and synthetic fibers.
performance parameters
model |
traffic |
Head lift |
Rotational speed |
power |
m3/h |
m |
r/min |
KW |
|
GBF25-125 |
4 |
20 |
2900 |
0.75/1.1 |
GBF25-125A |
3.6 |
20 |
2900 |
0.55/0.75 |
GBF25-160 |
4 |
32 |
2900 |
1.5/2.2 |
GBF25-160A |
3.7 |
32 |
2900 |
1.1/1.5 |
GBF40-125 |
6.3 |
20 |
2900 |
1.1/1.5 |
GBF40-125A |
5.6 |
16 |
2900 |
0.75/1.1 |
GBF40-160 |
6.3 |
32 |
2900 |
2.2/3 |
GBF40-160A |
5.9 |
28 |
2900 |
1.5/2.2 |
GBF40-200 |
6.3 |
50 |
2900 |
4/5.5 |
GBF40-200A |
5.9 |
44 |
2900 |
3/4 |
GBF50-125 |
12.5 |
20 |
2900 |
1.5/2.2 |
GBF50-125A |
11 |
16 |
2900 |
1.1/1.5 |
GBF50-160 |
12.5 |
32 |
2900 |
3/4 |
GBF50-160A |
11.7 |
28 |
2900 |
2.2/3 |
GBF50-200 |
12.5 |
50 |
2900 |
5.5/7.5 |
GBF50-200A |
11.7 |
44 |
2900 |
4/5.5 |
GBF65-125 |
25 |
20 |
2900 |
3/4 |
GBF65-125A |
22.3 |
16 |
2900 |
2.2/3 |
GBF65-160 |
25 |
32 |
2900 |
4/5.5 |
GBF65-160A |
23.4 |
28 |
2900 |
4/5.5 |
GBF65-200 |
25 |
50 |
2900 |
7.5/11 |
GBF65-200A |
23.5 |
44 |
2900 |
7.5/11 |
GBF80-125 |
50 |
20 |
2900 |
5.5/7.5 |
GBF80-125A |
45 |
16 |
2900 |
4/5.5 |
GBF80-160 |
50 |
32 |
2900 |
7.5/11 |
GBF80-160A |
46.7 |
28 |
2900 |
7.5/11 |
GBF80-200 |
50 |
50 |
2900 |
15/18.5 |
GBF80-200A |
47 |
44 |
2900 |
11/15 |
GBF100-125 |
100 |
20 |
2900 |
11/15 |
GBF100-125A |
89 |
16 |
2900 |
7.5/11 |
GBF100-160 |
100 |
32 |
2900 |
15/18.5 |
GBF100-160A |
93.5 |
28 |
2900 |
11/15 |
GBF100-200 |
100 |
50 |
2900 |
22/30 |
GBF100-200A |
93.5 |
44 |
2900 |
18.5/22 |
GBF125-125 |
160 |
20 |
2900 |
15/18.5 |
GBF125-125A |
143 |
16 |
2900 |
11/15 |
GBF125-160 |
160 |
32 |
2900 |
22/30 |
GBF125-160A |
150 |
28 |
2900 |
18.5/22 |
GBF150-125 |
160 |
20 |
2900 |
15/18.5 |
GBF150-125A |
150 |
16 |
2900 |
11/15 |
GBF150-160 |
160 |
32 |
2900 |
22/30 |
GBF150-160A |
150 |
28 |
2900 |
18.5/22 |
