The SA75T-EX explosion-proof vibration temperature transmitter is a small integrated, independent three wire (or four wire), probe type transmitter. Its two 4-20mA output signals are directly proportional to the true effective value (intensity) of the vibration velocity of the measured object and the temperature change at the measurement point.

Product Details

SA75T-EX Explosion proof Vibration Temperature Transmitter

SA75T-EX Explosion proof Vibration Temperature TransmitterIt is a small integrated, independent typethreelinear system(Or four wire system)Probe type transmitter. Its two paths4～20mAThe true effective values of the output signals and the vibration velocity of the measured object, respectively(intensity)Directly proportional to the temperature change at the measurement point.

This transmitter is easy to install and suitable for various large and medium-sized rotationsmachineConduct online measurement of vibration safety and temperature rise safety with sports equipment such as fans, water pumps, reducers, bearing seats, rolling friction bodies, etc. This transmitter can be used withDCSThePLCWait for the computer measurement and control system to connect.

Technical Specifications:

product structure	Integrated installation type, integrating vibration and temperature transmitters
power supply voltage	+24V DC
Vibration range	The commonly used range is vibration velocity: 0-20mm/s Optional vibration displacement: 0-200um vibration acceleration: 0-10g It can be selected within the range of 0-200mm/s (vibration velocity)/0-2000um (vibration displacement acceleration 0-20g) according to different devices
temperature range	-50 ℃~150 ℃ (optional within the above range, if the bearing temperature is between 0-100 ℃)
output signal	3-wire system, two 4-20mA outputs (temperature and vibration)
measurement accuracy	Vibration: ± 5%; Temperature: ± 2%
Vibration frequency response	10Hz～1000Hz
operating temperature	-20℃～80℃
Overall dimensions	Φ40×95mm
Shell material	Adopting stainless steel shell, double-layer isolation, strong anti-interference ability
install thread	M27×2(Customizable) M20X1.5, M16X1.5; M10X1.5, etc; Or magnetic suction seat installation.
Length of temperature probe	According to the depth of the on-site opening.
Wiring Instructions	brownColor -+24V DCpower supply blueColor vibration output 4-20mA blackColor temperature output 4-20mA
Installation Instructions	First, open an installation screw hole on the bearing seat or casing, and screw the nut on the bottom screw of the transmitter into the hole. The installation thread specification is generally M27×2(with thread length of 1)5mm）， Need to confirm the depth of the temperature measurement hole)

3、 Wiring method

Electrical connection:Brown:+24V DC

Blue: Vibration output

Black: Temperature output

4Appearance and installation

Temperature probe length：(including threads)customizable

Installation specifications for external threads:M27X2(or customized)Or magnetic attraction, etc）
